The Clenergy Wind Deflector (WD-CV11/10/2450M) is a structural aerodynamic component for the PV-ezRack Ascent flat roof mounting system, specifically designed to reduce wind uplift forces on solar arrays at a 10° tilt angle. Manufactured from MAC Steel (Zn-Mg-Al alloy coated steel), it delivers superior corrosion resistance and structural performance for commercial and industrial flat roof installations.
Key Features:
- 10° wind deflector for flat roof solar installations using the PV-ezRack Ascent 1.1 system
- Length: 2,450mm — spans the full width of the array row
- MAC Steel (Zn-Mg-Al alloy coated) — superior corrosion protection versus standard galvanised steel
- Engineered to reduce wind uplift, enabling lower ballast weight requirements
Wind deflectors are critical on flat and low-pitch commercial roof installations to manage aerodynamic loads on solar arrays. The WD-CV11/10/2450M is part of the Clenergy PV-ezRack Ascent 1.1 flat roof system, working in conjunction with front legs, rear legs, and main bases to form a complete, structurally tested ballasted mounting system. Tested to TUV and Eurocode structural standards.
